STORM PVC JUNCTION – 375X225mm, 90º

The Holman Junction is for use with Stormwater pipes. Our fittings are designed with a high impact strength which helps prevent damage during handling and installation. All parts assemble easily using solvent cement. Suitable for above and below ground applications. Watermarked approved meaning the products have been independently assessed as quality products. Complies with AS/NZS1254 – AMI 70007.

Size: 375x225mm
Degree: 90º
SKUJUNSW375x225x90 Category Tag
Close
Additional information
Size

375x225mm

Degree

90º

Close
Reviews
CodeDescriptionBagBoxPallet
SWF065075mm 45º1030540
SWF066075mm 90º10701260
SWF067090mm 45º-24432
SWF068090mm 90º-40720
JUNM150X150X45150mm 45º-6-
JUNM150X150X90150mm 90º-8-
JUNM150X100X45150mm x 100mm 45º-8-
JUNSW150X100X90150mm x 100mm 90º (F)---
JUNM225X225X45225mm 45º-2-
JUNM225X225X90225mm 90º-4-
JUNM225X100X45225mm x 100mm 45º-4-
JUNM225X100X90225mm x 100mm 90º-4-
JUNM225X150X45225mm x 150mm 45º-4-
JUNM225X150X90225mm x 150mm 90º-4-
JUNSW300X300x45300mm 45º (F)---
JUNSW300X300x90300mm 90º (F)---
JUNM300X100X45300mm x 100mm 45º-2-
JUNSW300X100X90300mm x 100mm 90º (F)---
JUNM300X150X45300mm x 150mm 45º-2-
JUNSW300X150X90300mm x 150mm 90º (F)---
JUNSW300X225X45300mm x 225mm 45º (F)---
JUNSW300X225X90300mm x 225mm 90º (F)---
JUNSW375x375x45375mm 45º (F)---
JUNSW375x375x90375mm 90º (F)---
JUNSW375x100x45375mm x 100mm 45º (F)---
JUNSW375x100x90375mm x 100mm 90º (F)---
JUNSW375x150x45375mm x 150mm 45º (F)---
JUNSW375x150x90375mm x 150mm 90º (F)---
JUNSW375x225x45375mm x 225mm 45º (F)---
JUNSW375x225x90375mm x 225mm 90º (F)---
JUNSW375x300x45375mm x 300mm 45º (F)---
JUNSW375x300x90375mm x 300mm 90º (F)---

Tech Sheet 75mm

slab repair coupling

Tech Specs

  • Model Name: Storm PVC Junction 75mm 45°
  • Colour: Grey
  • Connection: Yes
  • Material: Poly Vinyl Chloride – PVC
  • Watermark Certificate: AS/NZS1254 – AMI 70007
CodeDescriptionAngleSizeDimensionsWeight
SWF065075mm 45°45°75mmW:80 H:170 L:1300.25kg
SWF066075mm 90°90°75mmW:147 H:45 L:280.11kg

Tech Sheet 90mm

slab repair coupling

Tech Specs

  • Model Name: Storm PVC Junction 90mm 45°
  • Colour: Grey
  • Connection: Yes
  • Material: Poly Vinyl Chloride – PVC
  • Watermark Certificate: AS/NZS1254 – AMI 70007
CodeDescriptionAngleSizeDimensionsWeight
SWF067090mm 45°45°90mmW:95 H:20 L:200.28kg
SWF068090mm 90°90°90mmW:95 H:130 L:1600.18kg

Tech Sheet 150mm

slab repair coupling

Tech Specs

  • Model Name: Storm Fabfit Junction 150mm 45°
  • Colour: Grey
  • Connection: Yes
  • Material: Poly Vinyl Chloride – PVC
  • Watermark Certificate: AS/NZS1254 – AMI 70007
CodeDescriptionAngleSizeDimensionsWeight
JUNM150X150X45150mm 45°45°150mmW:320 H:355 L:1501.36kg
JUNM150X150X90150mm 90°90°150mmW:240 H:285 L:1500.99kg
JUNM150X100X45150mm x 100mm 45°45°150mm x 100mm0.99kg
JUNSW150X100X90150mm x 100mm 90° (F)90°150mm x 100mm

Tech Sheet 225mm

slab repair coupling

Tech Specs

  • Model Name: Storm Fabfit Junction 225mm 45°
  • Colour: Grey
  • Connection: Yes
  • Material: Poly Vinyl Chloride – PVC
  • Watermark Certificate: AS/NZS1254 – AMI 70007
CodeDescriptionAngleSizeDimensionsWeight
JUNM225X225X45225mm 45°45°225mm6.2kg
JUNM225X225X90225mm 90°90°225mm3.32kg
JUNM225X100X45225mm x 100mm 45°45°225mm x 100mm2.78kg
JUNM225X100X90225mm x 100mm 90°90°225mm x 100mm2.84kg
JUNM225X150X45225mm x 150mm 45°45°225mm x 150mm3.34kg
JUNM225X150X90225mm x 150mm 90°90°225mm x 150mm2.93kg

Tech Sheet 300mm

slab repair coupling

Tech Specs

  • Model Name: Storm Fabfit Junction 300mm 45° (F)
  • Colour: Grey
  • Connection: Yes
  • Material: Poly Vinyl Chloride – PVC
  • Watermark Certificate: AS/NZS1254 – AMI 70007
CodeDescriptionAngleSizeDimensionsWeight
JUNSW300X300x45300mm 45° (F)45°300mm
JUNSW300X300x90300mm 90° (F)90°300mm
JUNM300X100X45300mm x 100mm 45º45°300mm x 100mm
JUNSW300X100X90300mm x 100mm 90º (F)90°300mm x 100mm
JUNM300X150X45300mm x 150mm 45º45°300mm x 150mm
JUNSW300X150X90300mm x 150mm 90º (F)90°300mm x 150mm
JUNSW300X225X45300mm x 225mm 45º (F)45°300mm x 225mm
JUNSW300X225X90300mm x 225mm 90º (F)90°300mm x 225mm

Tech Sheet 375mm

slab repair coupling

Tech Specs

  • Model Name: Storm Fabfit Junction 375mm 45º (F)
  • Colour: Grey
  • Connection: Yes
  • Material: Poly Vinyl Chloride – PVC
  • Watermark Certificate: AS/NZS1254 – AMI 70007
CodeDescriptionAngleSizeDimensionsWeight
JUNSW375x375x45375mm 45º (F)45°375mm
JUNSW375x375x90375mm 90º (F)90°375mm
JUNSW375x100x45375mm x 100mm 45º (F)45°375mm x 100mm
JUNSW375x100x90375mm x 100mm 90º (F)90°375mm x 100mm
JUNSW375x150x45375mm x 150mm 45º (F)45°375mm x 150mm
JUNSW375x150x90375mm x 150mm 90º (F)90°375mm x 150mm
JUNSW375x225x45375mm x 225mm 45º (F)45°375mm x 225mm
JUNSW375x225x90375mm x 225mm 90º (F)90°375mm x 225mm
JUNSW375x300x45375mm x 300mm 45º (F)45°375mm x 300mm
JUNSW375x300x90375mm x 300mm 90º (F)90°375mm x 300mm
